Wooden sliding system Xperta wood

doorwooden doorintegrated soft-close mechanism

Product description
Xperta wood is a universal sliding door system designed for wooden doors up to 100 kg. Its unique track profile and low-noise rollers ensure smooth, reliable movement. Braking is provided either by a robust stainless steel stopper or by a compact double-acting soft close mechanism integrated into the profile. The soft close function is available from door widths of 600 mm. The universal track profile can be mounted directly to the ceiling or discreetly connected to the wall via a slim wall profile.

What makes Xperta wood so unique?

• Innovative technologies
  • Double-acting noiseless soft close
  • Extremely quiet wheels for reduced operational noise
  • Modular profile combinations for various installations
  • Smooth compact suspensions to minimise gaps
  • Available in black & white powder coating or grey anodization
• Easy-to-install sliding door
  • For complex mounting situations, an ESSI® module enables installation and replacement of all components within the profile without full disassembly, simplifying on-site work.
• Unique running track
  • The Xperta track features a bevelled profile for consistent roller guidance; the anodized variant enhances quiet operation.
• Bearing wheels
  • Wheels combine a soft core for cushioning and noise reduction with a hard outer layer to prevent deformation and extend service life.
• Soft close system
  • Provides gentle, safe opening and closing. The mechanism engages via a tilting motion with the designated roller and brakes the door in both directions (double-acting). Applicable from 600 mm door width.
• Available door width profiles
  • Through modular wall profiles, Xperta supports profile widths of 40/44 mm (with or without plinth) and 50/54 mm.
• Compact suspension possible
  • With compact suspension the gap between door and profile can be reduced to a minimum of 4 mm.
• Universal cover profile
  • In non-compact suspension a universal cover profile is used for both wall and ceiling mounting; plastic snap-fit pieces secure finishes to the profile.

Configurations and additional functionality

• Symmetrical doors
  A symmetrical configuration enables simultaneous movement of two doors for wider passages, coordinated by a reinforced toothed belt; suitable for ceiling and wall mounting.
• Telescopic doors
  The telescopic option allows separation of spaces using two or three panels that stow compactly along a narrow wall. Available with carrier-based or toothed-belt systems.

Technical specifications

• Group: sliding door hardware
• Material / finish: wood applications, surface-mounted
• Type: sliding
• Door thickness: 40 to 54 mm
• Maximum door weight: up to 100 kg
• Mounting: ceiling or wall-mounted
• Soft close: double-acting soft close (from 600 mm door width)
• Available finishes: black & white powder coating or grey anodization
• Available profile widths: 40/44 mm (with or without plinth) or 50/54 mm
• Minimum gap with compact suspension: 4 mm
• Universal cover profile: plastic snap-fit pieces for secure fit with various finishes
