Type:
1D - QRD Diffuser
Scattering range:
350 Hz to 6000 Hz
Purpose
- Improving low-frequency response
- Flutter echo control
- Specular reflection control
- Enlarging sweet spot
Lagos Fabric is the result of extensive research into diffusion techniques – it is based on a traditional QRD diffuser, but combine varying widths with each cell depth, overcoming some of the limitations of the standard QRD diffuser.
Using exclusive acoustically transparent fabric.
A discreet fabric covered diffuser that preserves all the functionality of the diffuser, whilst fitting perfectly into a continuous fabric design.
The phase grating surface of the diffuser is designed to provide a more uniform sound field through mid-high frequency diffusion. The well depths are individually tuned to enhance performance at certain frequencies, essentially increasing the effective range of the panel, without compromising the overall linear response – Lagos performs 15-20% lower with a linear frequency response.
Recommended for
- Home Cinema
- Home Theater
- Media Room
- Living Room
Why use diffusion?
Diffuser panels scattering incoming sound waves into smaller, lower energy waves, scattered over a large area. These scattered reflections create a homogeneous sound field distribution and a full, balanced acoustic response. This improves speech intelligibility, music quality, and creates a more uniform, larger sweet spot.
This product is available in the following Fire Rate:
FG | Furniture Grade
PRODUCT COMPOSITION:
Lagos F | Weave Fabric Finish (FG) *
- Weave Acoustic Fabric
- HMDF and plywood structure
