Service door PERSONNEL & EMERGENCY EXIT

woodentwo-waywithout glazing

Specially designed personnel doors are available for all Astron wall systems. Our doors are preassembled, including frame, door leaf and accessories. It makes the installation very simple. All details and parts are designed to fit perfectly in the Astron façade. A single or double leaf swing door, which can be used as a personnel door or can be equipped with an anti-panic device for emergency exit doors. TYPE AND COMPOSITION Single swing door opening to the outside: Door frame – steel profile of 1.5 mm thickness, galvanised and powder coated with a light grey primer. Door leaf – total thickness 65 mm, steel sheets 1 mm, galvanised, powder coated with a light grey primer, lock, high density mineral wool insulation. The clear width is 1 m. Clear height is 2.084 m. Supplementary components – handles or knob, lock cylinder and three keys, alu sill profile and joint, peripheral rubber joint, fixing clips and hardware, flashings and weatherproof material, ready to be installed easily and quickly in our facades. Opening mode – DIN L or DIN R. Double swing door opening to the outside: Consisting of a main opening leaf identical to that of the single swing door. The fixed leaf is anchored at top and bottom by a latch. The clear width of the main leaf is 1 m and for the fixed leaf 800 mm. Clear height is 2.084 m. Opening mode – DIN L or DIN R. Emergency exit door, single or double leaf opening to the outside, equipped with an anti-panic bar and an outside handle or door knob. The above single and double swing doors can be equipped with anti-panic bar inside and a handle or a fixed knob outside.
