Three-point closing system
The SECURITY fire door adds to fire safety, security in access control by means of a three-point anchorage.
POINTS
Wide range of standard dimensions in two different heights in order to optimise projects. This is reflected in a great combination quality/price.
Non-standard dimensions in order to adapt the door to any need.
Torsional rigidity of the door leaf higher than that of traditional assembling method.
Galvanized sheet and paint with a high corrosion resistance and durability.
Thermal insulation 1.2 (W/m2k).
Open Z frame for an easy installation.
Excellent serial hardware.
Includes a self-closing hinge.
Great variety of hardware in stock (see hardware catalogue).
Tested for up to 200.000 opening and closing cycles.
Certified as a whole.
CERTIFICATES
Fire resistance of 60 and 90 min according to the European Norm EN 1634-1:2000 and ANSI/UL 10B-2009 “Fire Tests of Door Assemblies”.
Durability certificate C5 according to the European Norm EN 14600:2005.
Certificate ISO 9001:2008
DOOR LEAF
Galvanized steel sheets 0.7/0.9 mm thick, profiler-assembled by double folding and stiching together the LID-TRAY set.
Also available in stainless steel.
High density rock wool insulation, 145/180 kg/m3.
Galvanised steel stiffeners.
Hexagonal 14x36 mm zinc plated anti-leverage bolt.
Door thickness: 51 mm, approx.
Leaf bottom prepared for the installation of a guillotine.
