Electric radiant panel F120wallresidentialcommercial
Add to favorites
Compare this product
Characteristics
- Power source
- electric
- Installation
- wall
- Sector
- commercial, residential
- Power
- 1500 w, 500 w, 2000 w, 2001 w...2500 w, 1000 w
- Color
- white
- Length
460 mm
(18 in)- Width
390 mm, 470 mm, 610 mm, 760 mm, 910 mm
(15 in, 19 in, 24 in, 30 in, 36 in)- Depth
110 mm
(4 in)- Weight
3.1 kg, 3.7 kg, 4.6 kg, 5.5 kg, 6.4 kg
(6.83 lb, 8.16 lb, 10.14 lb, 12.13 lb, 14.11 lb)
Description
Short description
Wall-mounted electric heating panel with Wi‑Fi connectivity and open-window detection for scheduled and remote control.
The perks of F120 Connect
Discover the product
COMFORT
ENERGY SAVINGS
INSTALLATION
Models
Technical specifications
Wall-mounted electric heating panel with Wi‑Fi connectivity and open-window detection for scheduled and remote control.
The perks of F120 Connect
- Weekly programming for reduced energy use
- Open/close window detection
- Homogeneous and fast heat diffusion
- Wi‑Fi connection and remote piloting
Discover the product
COMFORT
- Quick and homogeneous heat diffusion thanks to even distribution across the appliance surface
- Sheathed heating element with aluminium diffuser for uniform temperature
ENERGY SAVINGS
- Wi‑Fi connectivity with remote piloting and app control
- Weekly programming with daily presets and electronic regulation
- Open/close window detection to avoid energy loss
INSTALLATION
- Class II electrical insulation and IP24 protection for safe operation
- H-shaped vertical support for straightforward wall mounting
Models
- F120 Connect 500W — Output: 500 W; Connectivity: Yes; Dimensions (L x H x D): 460 x 390 x 110 mm; Open window detection: Yes
- F120 Connect 1000W — Output: 1000 W; Connectivity: Yes; Dimensions (L x H x D): 460 x 470 x 110 mm; Open window detection: Yes
- F120 Connect 1500W — Output: 1500 W; Connectivity: Yes; Dimensions (L x H x D): 460 x 610 x 110 mm; Open window detection: Yes
- F120 Connect 2000W — Output: 2000 W; Connectivity: Yes; Dimensions (L x H x D): 460 x 760 x 110 mm; Open window detection: Yes
- F120 Connect 2500W — Output: 2500 W; Connectivity: Yes; Dimensions (L x H x D): 460 x 910 x 110 mm; Open window detection: Yes
- F120 Connect Mobile 500W / 1000W / 1500W / 2000W / 2500W — portable versions with same connectivity and open window detection where indicated
Technical specifications
- Brand: Atlantic
- Commercial name / model: F120 Connect
- Connectivity: Wi‑Fi (remote piloting), Cozytouch compatibility indicated
- Open window detection: Yes
- Programming: Weekly programming; electronic regulation
- Heating element: Sheathed heating element with aluminium diffuser for even heat distribution
- Safety / protection: Class II electrical insulation; IP24
- Installation: H-shaped vertical support for easy mounting
- Available outputs: 500 W, 1000 W, 1500 W, 2000 W, 2500 W
- Dimensions vary by output (L x H x D in mm): 460 x 390 x 110; 460 x 470 x 110; 460 x 610 x 110; 460 x 760 x 110; 460 x 910 x 110
