Wall-mounted loudspeaker FX3.15
activeresidentialcommercial

Wall-mounted loudspeaker - FX3.15 - Audac - active / residential / commercial
Wall-mounted loudspeaker - FX3.15 - Audac - active / residential / commercial
Add to favorites
Compare this product


Characteristics

Type
wall-mounted
Technical characteristics
active
Sector
residential, commercial
Interior/exterior use
outdoor
Material
plywood
Shape
rectangular
Color
black
Height

456 mm
(18 in)

Width

714 mm
(28.1 in)

Depth

580 mm
(22.8 in)

Weight

47.5 kg
(104.72 lb)

Power

750 W, 1,500 W, 3,000 W

Description

High-output cabinet 15" High quality 18 mm plywood Integrated carry handle on both sides Integrated metal rigging frame DuraCoat™ texture paintwork High output 3-way active driven system 90° x 40° Rotatable horn The FX series is a unique and versatile speaker system series. When you combine the FX1.18 bass cabinet with the FX3.15 3-way active speaker cabinet, this truly modular system can be scaled and adapted for every application where a powerful system with a high clarity and sound quality is required. The compact enclosures are provided with durable and scratch resistant DuraCoat textured paintwork and are fitted with eight carry handles allowing easy carriage and handling of the system. The integrated metal rigging frame allows easy and secure rigging, allowing multiple cabinets to be rigged together. The FX3.15 is a 3-Way high-output, active driven compact High / Mid / Mid-Bass speaker cabinet which is a part of the unique and versatile FX series system. This three-way cabinet includes a 15” horn-loaded Mid-Bass driver, 6” loaded mid speaker and 1.75” PEEK (Polyether ether ketone) compression driver. The entire system has a power handling of 750 Watt RMS with a maximum power of 1500 Watt. The Mid-Bass section takes part for 500 Watt RMS while the Mid section takes part for 200 Watt RMS and the High section represents 50 Watt RMS. The horn with a coverage pattern of 90° x 40° incorporates both High and Mid frequency drivers which can be rotated allowing complete flexibility in selection of horizontal & vertical as well as left & right positioning.
