Pedestal ashtray TDA-11-DB-2020

galvanized steelstainless steelpolyethylene

Volume: 8 Liter Casing material thickness: 1,5 mm Tubular frame material: 1.4301 (AISI 304) stainless steel, brushed Tubular frame material thickness: 2,5 mm Ash collector material: galvanized steel Width: 551 mm Depth: 300 mm Height: 1857 mm Information-frame: Polyethylene sheet (2 x 1 mm) Hard foam plate (5 mm) DIN A2 Weight: Approx. 31 kg Description: Outdoor floor-standing ashtray with cover and information-frame, self-supporting construction. 6 mm thick base plate (including 4 boreholes for floor mounting), tubular framework with additional round strut (safety feature for visually impaired and blind persons). Ashtray with flat fronts and sides, slitted grid and funnel shaped, oblong insert. The disposal of cigarette packs is not possible. Safety: Snap locks protect the ashtray against unauthorized access. Funnel top secured by a non-projecting 8 mm square lock (a key is supplied with each ashtray). Handling: Quick and easy removal of the ashcollecting-tray from above after operating the lock (1/4 turn). Handling of the information-frame: The interchangeable frame allows easy mounting of posters or signs. Loosen the hexagon socket screws (key is enclosed) and remove the upper part of the frame to change the posters / signs.
