Interior door LP20

firMDFswing

Overview
The PantoClassica collection of hand-lacquered doors is distinguished by top-quality lacquering performed according to CATAS-certified standards for colour fastness and anti-yellowing. The lacquered finish is applied with water-based paint to ensure a lower environmental impact and long-lasting appearance. This model combines traditional, harmonious lines with high technical performance for a demanding, design-oriented clientele.

Frame and construction
PantoClassica doors are supplied with the TR frame: a classic profile that complements the soft, sinuous contours of the pantograph machining. Frames are made in sandwich material while edge covers are manufactured in IDRO, CARB and FSC® certified MDF, ensuring an extremely flat surface ideal for lacquering. The flush-fitting TKT frame (push side, reversa) is available on request.

Details

• TR frame certified IDRO, CARB and FSC®
• IPER 4 BOARD door edging on all four sides
• Leaf structure built with selected fir strips; Made in Italy
• Honeycomb core ECO bee made with 100% recycled paper
• Solid imitation finish as standard
• ACU PLUS acoustic gaskets as standard
• Concealed hinges and magnetic lock as standard
• Optional NO-GERMS anti-bacterial treatment
• High customisation possibilities
• Available in various opening types
• Also available as a coating for armored doors
• Also available on EI fire-rated doors
• Certified acoustic door option available
• Available with extra-clear or frosted transparent glass inserts
• Adjustable anti-sagging tie-rods standard for heights over 2400 mm
• Matches IDRO MDF skirting
• Mechanical components installed using TORX screws

Technical specifications

• Model: LP20
• Collection: PantoClassica (hand-lacquered doors)
• Finish: Matt Ivory lacquer
• Lacquering: CATAS-certified for colour fastness and anti-yellowing
• Paint: water-based lacquer (low environmental impact)
• Frame: TR sandwich frame; TKT flush-fitting version available on request
• Edge covers: IDRO, CARB and FSC® certified MDF
• Door edging: IPER 4 BOARD on all four sides
• Leaf structure: fir strips from selected wood, Made in Italy
• Core: honeycomb ECO bee (100% recycled paper)
• Standard features: ACU PLUS acoustic gaskets, concealed hinges, magnetic lock
• Optional treatments: NO-GERMS anti-bacterial, fire-rating (EI), armored door coating
• Accessories/options: extra-clear or frosted glass inserts, adjustable anti-sagging tie-rods for heights >2400 mm, matching IDRO MDF skirting
• Mechanical fixings: TORX screws
