Mechanical thermostatic valve V3

manualfor heatingfor ventilation system

Accurately control the flow of hot water, or chilled water through coils and heat exchangers of all types, in a wide range of Heating, Air Conditioning and Ventilation applications. V3 series electric ball valve are 3-wire control actuator with DN15~DN40 valve body, Screw connection makes the valve body and actuator very easy for installation Bi-directional permanent magnetic synchronous motor design has been proven reliable in millions of installations worldwide. Electric ball valves, also called motorized electric ball valves, are used to control the flow of a media (liquid or gas). The rotating ball is controlled by an electric actuator directly connected to the ball valve stem. The electric ball valve can be divided into two main components: the electric actuator and the ball valve. Breeze V3 series electric ball valve has the advantages of simple operation, reliability, long service life, and a wide range of applications. It is one of the most common valves. Safe and Reliable 1. The V3 series electric ball valve has a service life of 100,000 cycles. 2. Complete sealing can be achieved within a wide pressure and temperature range. 3. Both sides of the working medium are sealed reliably. 4. Can well withstand the stress of pipelines. 5. Quick opening and closing.
