Pellet boiler HYDROCONFORT 23

with water heaterresidentialindoor

FastOn Oasys Plus Double Cleaning System New Layout of the Burner Modulation System Model designed for easy access to maintenance service Load Level Sensor Model Compatible with Kit Wifi Programmable Power max: 23kw Power transferred to the water: 20-5kw Efficiency: 82-87 % Consumption max-min: 4,8-1,2 kg/h Power consumption: 150-450W Heating capacity: 500 m3 Tank capacity: 60 Metallic interior Autonomy (min-max): 8,9-40h Weight: 255kg Fume outlet diameter: 100mm Air inlet diameter: 60mm Working pressure: 1,5bar Working maximum pressure: 3bar Underfloor heating: 200*(m2) Nº radiator elements: 143* Closed expansion vessel: 6l Maximum service temperature: 40/80°C Valve for drinning water Circulating pump Weekly programmer Automatic ignition Hermetic tank Management Heating / Sanitary Water Security system: S2. Safety thermostat pellet, Safety thermostat water, Air flow switch, Safety valve 3 bar, Pressure setting valve Compatible accesories not included: VAL-02/VAL-04/KIT WIFI DOUBLE CLEANING SYSTEM A 360-degree spin of the base of the burner New patented heat exchange system. Cast-iron burner Thermally insulated chamber. Combustion chamber window. Automatic air vent included. Grafic LCD color Touch of 3.5”for programming and controlling the boiler. Height adjustable levelling feet. * The calculation of radiators and underfloor heating has been determined according to normal conditions of a house insulation, located in a temperate zone. Aluminium radiator elements have been considered with a height of 60cm and a temperature difference of 50º, 120 kcal/element. Check characteristics (power) of the radiator. Energy efficiency class: A+ Certifications: EN-303-5, EcoDesign
