Square shaped - up and down - luminaire combines brilliant LED light with straightforward design. Oppositely arranged, the two LED sources generate an up-and downwardly directed, various light beams. Manufactured in different sizes.
Designed to last in extremely harsh environments.
LED Type - High efficiency LEDs, available in 2700K, 3000K, 4000K, 5000K, 6500K CCT tolerance within a 3-step MacAdams ellipse and LM80 compliant.
Nominal Voltage - 220V-240V AC, 50/60Hz
Color Rendering Index - CRI> 80 standard and CRI>90 on request.
Optics - One and two sided 8° / 12° / 30° / 45° / 60° / 90° and asymmetrical beam.
Materials - Corrosion resistant double layer polyester powder coated paint finish aluminium housing (EN AW-6060) with stainless steel screws (A4 grade) and silicone gaskets. Power unit is built in. Available in anthracite gray as a standard finish or any desired RAL colour.
Optional Coating - Marine grade.
Diffuser - Thermal-shock resistant tempered glass.
LED Specification. - L90B50 > 100000 hours life time.
Energy Effciency Class (EEC) - A++
Operating Temperature - -40°C / +55°C
Power Factor - >0.95
Protection Class - IP66
Impact Resistance - IK10
Insulation Class - Class I
Conformity - Complies with European Standards EN 60598 and CE certified.
