iAxis Edge is a durable and virtually maintenance free surface mounted luminaire suitable for a wide range of wall washing, accent, surface grazing and indirect lighting applications in architectural, hospitality and retail environments, it has multiple customization options to illuminate interior walls, exterior facades and unique architectural details. Confirms vibration standards for bridge applications.
Designed to last in extremely harsh environments.
Monochrome or DALI controllable, easy to install with the remote universal power supply and connect via combined power and data connectors.
LED Type - High efficiency LEDs, available in 2700K, 3000K, 4000K, 5000K, 6500K CCT tolerance within a 3-step MacAdams ellipse and LM80 compliant. Custom LED color combinations available.
Nominal Voltage - 24V DC
LED Pitch (mm) - 41
Color Rendering Index - CRI> 80 standard and CRI>90 on request.
Optics - Standard: 8° / 12° / 25° / 30° / 45° / 60° / 90° / 18°x38° / 15°x50° / 25°x50°
Asymmetrical Linear Wallwash. Custom optics upon request.
Dimensions (mm) - A: 75 - 90 B: 59 C: 39
Materials - Corrosion resistant extruded anodized aluminium housing (EN AW-6060) with stainless steel screws (A4 grade) and silicone rubber gaskets. Operates with a remote driver. End-to-end connection via power connectors. Includes adjustable mounting brackets.
