iLevel is a dimmable encapsulated linear LED line, suited for installation in indoor and outdoor with a broad range of colours. It is a colour mixing linear light source in a compact, IP rated, silicone sealed aluminium profle with mounting brackets. Available in lengths to suit your application and provides a concealed, continuous linear glare and dot free illumination for discrete architectural details and accent lines.
Designed to last in extremely harsh environments.
LED Type - High efficiency LEDs, available in 2700K, 3000K, 4000K, 5000K, 6500K CCT tolerance within a 3-step MacAdams ellipse and LM80 compliant.
Nominal Voltage - 24 V DC
Color Rendering Index - CRI> 80 standard and CRI>90 on request.
Optics - 120°
Materials - Corrosion resistant extruded anodized aluminium housing (EN AW- 6060) with stainless steel screws (A4 grade) and silicone rubber gaskets. Operates with a remote driver. Includes waterproof connectors. BSILINEA® LED Module.
Optional Coating - Marine grade.
Diffuser - Shockproof PMMA UV Stabilised Diffuser.
LED Specification. - L90B50 > 100000 hours life time.
Energy Effciency Class (EEC) - A++
Operating Temperature - -40°C / +55°C
Power Factor - >0.95
Control Systems - DALI Interface (External)
Protection Class - IP65
Impact Resistance - IK08
Insulation Class - Class III
Installation - Suspension.
Conformity - Complies with European Standards EN 60598 and CE certified.
