Contemporary screen SLIDING FRAMED DOUBLE

glassaluminumcommercial

Specifications glassSCREENS > SLIDING FRAMED DOUBLE (STAF-2X) Floor-mounted and fully framed by aluminum profile, the double-layered glass panels are captured by both top and bottom rails. Option to conceal top track for minimal look. VALUE-ADDED BENEFITS Easy installation: pre-assembled door panel Efficient operation: simple hardware design Minimalist: small aluminum frame; option to fully conceal top track System durability and long-term integrity Turnkey integrated project services FACILITY DESIGN APPLICATIONS Space division between offices, conference rooms or flex-space, bathrooms. CONFIGURATIONS Single, single + fixed panels to match, side mounted, top mounted, concealed. FUNCTION Top-hung sliding double panel. GLASS TYPES Tempered monolithic. Tempered laminated. GLASS FINISHES Refer to Finish Chart CARVART laminated transparent glass design options available. SURFACES Smooth glass. Etched glass. GLASS THICKNESS Refer to local code and structural requirements Accommodates 1/4" nominal. HARDWARE DIMENSIONS Aluminum top track: 2-5/8" wide x 2" high nominal. Vertical side rails: 1-3/4" deep x 1/8" wide. Horizontal side rails: 1-3/4" deep x 1/8" wide. HARDWARE MATERIALS/FINISHES Refer to Finish Chart Satin anodized aluminum, polished aluminum, blackened aluminum. black, white, grey, midnight, charcoal, light grey, warm grey, champagne, terra cotta. WIDTHS — OVERALL MINIMUM/ MAXIMUM RANGE (inches): Glass panels: Minimum 29". Maximum 48". HEIGHTS — OVERALL MINIMUM/ MAXIMUM RANGE (inches): Glass panels: Minimum 18" height. Maximum 108" height above finished floors.
