The perfect flatness turns each piece into a work of art. The frontal furrow makes it personality and homogeneily to the roof. The laying of Vienna roof tile is carried out by straight bond.
DATA SHEET
Dimensions
a: 465 mm
b: 258 mm
c: 30 mm
Pieces per m2
11,5
Weight per piece
3.450 gr
Longitudinal fit
396 mm (+5;-75 mm)
Transversal fit
214 mm (±1 mm)
High definition
It provides a perfect definition on each piece, made with gypsum moulds, providing a much finer texture.
Excellent flatness
Individual curing of each tile thanks to support in H. Excellent flatness with no contact points.
Low absorption
Higher resistance to ice and mould formation.
Lifetime warranty
Our 100 years of warranty ensure your peace of mind and demostrate the quality of our manufacturing process.
Ample longitudinal overlapping (80mm)
Avoids cutting the tiles, therefore reducing time and installation costs
Higher resistance
The clay composition together with the perfect pressing allows flexion higher than the required while only weighing 3.45 kg.
Lower absorption (,5%)
High quality clay together with high firing temperature mean higher resistance to ice and mildew.
High definition on each piece
The gypsum moulds provides a perfect fi nish, obtaining a smoother texture, no contact points nor creases
Double interlocking
The double interlocking-horizontal and vertical- allows the roof to be more watertight, ensuring its impermeability.
Excellent flatness
H-Cassette manufacturing provides a perfect fi nish to each product.
Cost reduction
Its large format (11.5units/m2) and strapping every 6 units, as well as its packaging on pallets of 216 and 288 units, reduce installation costs
