General information
- CE-marked
- Meets requirements of EN 13241-1
- Wind load: any windload
- Door size: no size limitations
Fabric
- Mildew-, UV- and fire-resistant
- Weight 900 g/m2
- Tear strength: 550/550 N
- Tensile strength: 4000/4000 N/5 cm
- Heat and frost resistance +70 to -35 °C
- Best functionality to -35 °C, arctic fabric to -60 °C
- Fabric options: windows, Translucent, arctic, soundproofing, thermal insulation, security burglar protection
Other materials and surface treatments
- Upper console - hot-dip galvanized steel
- Side guides - aluminum profile
- Lower (bottom) beam - hot-dip galvanized steel
- Horizontal beams - aluminum
- Mullions - sandblasted, primed and painted (2 layers)
- Other parts - aluminum, nylon, stainless steel
Electrical system
- Enclosure class: IP54
- Operating voltage: 3x230/400 V 50 Hz
- Control voltage: 24 V
- Motor rating: 1 to 5 kW/motor
- Torsion: from 400 Nm to 4800 Nm/motor
Sound level
20 dB ->
