It allows you to choose from different irrigation timessimply by turning the dial: it doesn’t get any easier than that when it comes to underground irrigation!
MANAGES UP TO 6 INDEPENDENT LINES
DELAYED START
BUFFER BATTERY FOR MAXIMUM RELIABILITY
CAN BE CONNECTED TO RAIN SENSOR
Easy-to-program 6-line electronic timer: just turn the 6 dials to set the required irrigation schedule: 5 - 10 - 15 - 20 - 30 - 60 minutes. There is a frequency control for selecting the repetition of the watering programme at predefined intervals: 8h - 12h - 24h - 2 days - 3 days - 4 days - 7 days. There is a start button for immediate activation of the programme or the manual function for the system test phase - “start + ... hours” button for a 23-hour delay in activation of the programme. An intermittent LED system indicates valve opening. A safety timer delays valve opening by 5 seconds. Pump control. 9 V buffer battery. External 220 - 24 V transformer included. Compliant with CE standards. Designed for direct connection to the Rain Sensor.
Width: 215 mm
Height: 188 mm
Depth: 60 mm
Weight: 1063 g
body: ABS
wall bracket: ABS
cover lid: PC
Fixing: can be wall-mounted
Voltage: 24V AC
Outlets: 6
Programmes: 1
Type of programmes: preset
Max. frequency of watering cycles: 3 per day
Min. watering duration: 00:05′
Max. watering duration: 01:00′
Valves voltage: 24V AC
Rain sensor: wired
Powered by: 1x9V
Warranty (years): 3
