Polycrystalline hybrid solar panel

for heatingwith anti-reflective glassPID-free

Glass- antireflective, solar, tempered 3,2 mm Laminating foil (EVA) Ribbon Poly crystalline solar cells, PID free Laminating foil (EVA) Backsheet Junction box with Diotec bypass diodes IP-65 Cables 4 mm2, 2 x 1 m with MC4 connectors Anodized aluminum frame Integrated aluminum absorber Thermal insulation Aluminum cover Inlet/outlet fluid ø22 Sizes: 1650 х 990 х 40 mm Weight: 31kg This module performs simultaneously two functions – generates electricity and heats water. It is a combination of a photovoltaic module for electricity generation and solar thermal collector. The face of the PVT panel absorbs solar radiation and produces electricity and warmth. A highly effective absorber, integrated in the back of the solar cells takes away the heat and by means of a heat carrier (propylene glycol) warms water. And thanks to the heat removal, the photovoltaic cells are constantly cooled, thus increasing their performance and working with optimal efficiency.
