Industrial air handling unit TKS 60

indoor

Product overview
Dantherm TKS 60 is a free-cooling unit engineered to control the internal climate of communication shelters and similar enclosures while minimising energy consumption. Using controlled overpressure ventilation, the TKS 60 expels excess heat from sensitive equipment and keeps internal temperature within defined limits.

Key features

• Total heat management with emphasis on energy-efficient controlled ventilation
• Automatic change between cooling modes for optimal energy use
• Standard M5 fine bag filter; optional AirMaze (pat. pend.) for enhanced particle and water protection
• Built-in filter monitor to schedule maintenance and reduce unscheduled service visits
• Wide ambient operating range: -25 to 55°C
• User-friendly display for local climate control; Ethernet, SNMP and Modbus for remote monitoring and control
• Integrated CC3000 control system

Suitable for

• Data centres, telecom shelters and communication cabinets

Technical specifications

• Model variants: TKS 60 (230V AC) and TKS 60 (48V DC)
• Nominal air flow: 4,200 m³/h (TKS 60 230V AC); 3,200 m³/h (TKS 60 48V DC)
• Nominal cooling capacity (W/K, Δt = 1°C): 1,400 W/K (TKS 60 230V AC); 1,050 W/K (TKS 60 48V DC)
• Nominal fan power consumption (100% speed): 782 W (230V AC); 374 W (48V DC)
• Filter class: ePM10 55% (F5) (standard)
• Fan nominal voltage: 230V AC (230V model); 48 V DC (42–57 V DC) (48V DC model)
• Sound pressure @ 1 m: 67 dB(A) (230V AC); 64 dB(A) (48V DC)
• Controller: CC3000 integrated control system
• Communication interfaces: Ethernet (SNMP), Modbus
• Product size (H x W x D): 1100 x 600 x 600 mm
• Net weight: 53 kg (TKS 60 230V AC); 51 kg (TKS 60 48V DC)
• Optional AirMaze weather/air-path protection for improved resistance to wind-driven water and particulates
