Welded mesh fence AXYLE® MS

residentialfor public spacesgalvanised steel

Boundaries with a cost-effective small-fold panel - Uncut small-fold panel - Panel width : 2500 mm – High adherence polyester-coated galvanised steel wire - Mesh: 200 × 55 mm • Wire diameter : horizontal 5mm, vertical 4mm • 2 colours: Green 6005 and Grey 7016 • Center distance with AXOR® Plus column : 2535 mm • Center distance with AXYLE® column : 2533 mm SECURITY • Small reinforcement folds to ensure the panel’s rigidity. • Defensive spikes : can be installed with spikes on the upper or lower section (note: some privacy systems with a cap rail require installation with spikes on the highter section). DURABLE AND ATTRACTIVE • The number of reinforcement folds increases according to the height of the panel, ensuring optimal rigidity. • The thinner vertical wire gives greater subtlety to the end result. INSTALLATION • Recommended for use with AXOR® PLUS notched post or AXYLE® clip post • Compatible with LIXO® blackout systems
