DMX controller 0 BLE

Description
Wireless BLE DMX controller using CASAMBI technology. Programs and controls a DMX installation via the CASAMBI app on any smart device. Can be integrated into existing CASAMBI networks for centralized wireless lighting control.

Features

• Programming and scene recall via CASAMBI technology
• Device control using broadcast mode
• Required power supply: 230V
• DMX connection: screw terminals
• Compact dimensions: 115 x 123 x 62 mm
• Suitable for indoor and outdoor use (IP67 enclosure)

Versions (table)
Code | Wiring name | Kg | Colour | Length | Width
81420057 | S | 0.2 kg | Black | 115 mm | 123 mm

Notes
The reported luminous flux refers to the flux emitted by the light source with a tolerance of ±10% compared to the indicated value. The "W tot" column indicates the total power absorbed by the system with a maximum tolerance of 10% compared to the indicated value.

Technical specifications

• Model code: 81420057
• Wiring name: S
• Weight: 0.2 kg
• Colour: Black
• Dimensions (L x W x H): 115 x 123 x 62 mm
• Power supply: 230V
• DMX connection: screw terminals
• Wireless technology: CASAMBI (BLE)
• Control modes: programming and scene recall, broadcast mode
• Protection rating: IP67 (suitable for indoor and outdoor applications)
