Wooden scaffolding MULTI 4X EXMDS2

galvanised steelhigh

KEY FEATURES Multidirectional scaffolding with 4 positions for structural work and finishing work. standard compliant. Multidirectional with 4 positions. Safe assembly and disassembly level 2. Assembly and operating guardrails level 2. Safe assembly, disassembly and operating guardrails = exceptional wind bracing. Highly resistant steel structure Ø 50 - 2 mm thick. Corrosion protection by hot-dip galvanization. The structure has an incredible standing. Pinlock uprights with 4 positions. Reinforcements on uprights extremities. Fast, easy connection using captive cotters. Connection via shackles and captive cotters. 100% compatible with F3000 facade scaffolding. Compatibility allows for plenty of configurations. SPECIFICATIONS Light multidirectional scaffolding. Pinlock upright with 4 positions. Protection by assembly and operating guardrails. Label level 2 for safe assembly and disassembly. Galvanized steel. ISO 1461 hot-dip galvanization. Decree 2004-924. Compliant with European NF EN 12810 and 12811 standards. NF standard compliant. Class 4-300 daN/m². Ø 50 uprights 2 mm thickness. Pinlock uprights with 4 positions every 0.5 m. Uprights with crimped reinforcements at the end. Ø 40 mm girders. Girders fixed to uprights by pins every 90°. Connection via shackles and captive cotters. Shackles with pre-positioning claws. 1.61 m high EXMDS guardrail.
