PRODUCT DESCRIPTION
Easy to use RGB colour mixing Mini Chain LED IP67 using SSI Red, Green and Blue LEDs to mix any colour of your choice using our RGB simple colour controller. This will also vary intensity and perform other colour auto change functions.
Each module pre spaced on at 86mm centre to centre. Total 50 Modules per set. Modification to centres possible by cutting and inserting 4 core wire to form spaces/spacing as required.
Requires Constant Voltage power supply and RGB control. See separate part numbers.
Easy to use with our simple IR Colour controller
Fitting Advice
Each 4.3M 50 module set draws 32.5watts. If you are running two sets the total would be 65watts. You must select a power supply to suit e.g. a 25w power supply/transformer would not adequately run two sets. Orderv a PSU adequate for the length or number of modules. It is not recommended to run more than three sets in one line.
ADDITIONAL INFORMATION:
Input 12v DC
Length 4.3m 50 modules
Module Size L=52mm W=13mm H=11mm
RGB 3 Led 32.4W Per Set
IP Rating IP65
