Tempered glass panel BEAMSPLITTER

laminatedtransparentmirror effect

The particular application dictates whether you choose beamsplitter glass with 70% light transmission and 30% reflection, or our 50% option. Every single variant of the beamsplitter glass has an optical thin-film coating on one side that reflects and transmits light waves that fall upon it at a specific ratio. Choose from monolithic glass, laminated glass or toughened/tempered glass as the core material. To prevent ghosting, it is possible to have a single-sided LUXAR anti-reflective coating on the opposite side of all our beamsplitter glass sheets. technical data: beamsplitter (monolithic glass): 70/30%; 50/50% light transmission (coated side): 70%, 50% light reflexion (coated side): 30%; 50% Dual view: reflection and transmission of light Two degrees of light transmission and reflection available True-to-source color of both reflected and transmitted light Versatile design material, both for interior and exterior applications Coatings offer high durability and abrasion resistance in accordance with ISO standards Weatherproof and extremely low levels of absorption Supplied with protective film Customized beamsplitters are available upon request. Beamsplitter glass is a popular design material for applications where a high level of light transmission is required and where a mirror effect is essential. The best-known example is the teleprompter, which reflects the text displayed by a monitor using a two-way mirror positioned in front of the camera lens. Thanks to the two-way mirror’s transparency, camera operation is not affected.
