Zone Evo has a clean conical design and an efficient segmented reflector ensuring excellent visual performance.
Installation
Recessed.
Some models can be covered with insulation. For further details please refer to the assembly instructions on our website.
Connection
Connection in remote LED driver. Luminaire connects to driver with supplied cable.
Design
Housing in aluminium, powder coated black (RAL 9017) or white (RAL 9016) structured. Front ring in thermo plastic.
Reflector
Segmented reflector. In spot, medium and flood beam angle.
Dimming
DALI, phase pulse control. 100-1 %.
LED-information
3000 K: CRI 80 or 90, L80 B50 75 000 h, MacAdam 3 SDCM.
4000 K: CRI 80, L80 B50 75 000 h, MacAdam 3 SDCM.
Driver life-time up to 50 000 h/10 % (max failure).
Miscellaneous
Passived cooled in all versions. For more lumen packages, choose standard/DALI in the scroll list.
