PTZ security camera / box / wall-mounted / outdoor
ELARA™ FB-SERIES ID

{{requestButtons}}

Characteristics

  • Type:

    PTZ

  • Configuration:

    box

  • Installation:

    wall-mounted

  • Location:

    outdoor

  • Other characteristics:

    IP66, PoE, ONVIF

Description

The FLIR Elara™ FB-Series ID thermal security camera uses onboard analytics to classify human or vehicular intrusions, making it ideal for perimeter intrusion detection and sterile-zone monitoring. The Elara™ FB-Series ID can also hand off classified intrusions to FLIR PTZ cameras for autonomous tracking of intruders. Easy to set up, Elara™ FB-Series provide reliable detection with low false alarm rates in challenging environments, bad weather, and complete darkness.

RELIABLE ANALYTICS WITH FEW FALSE ALARMS
The Elara FB-Series ID classifies human and vehicle intrusions, and hand-off targets to autonomous PTZ tracking cameras.

"PLUG AND PLAY" INTEGRATION
The camera is fully certified by third party video management systems, as well as FLIR United VMS.

INDUSTRY-LEADING PERFORMANCE AND RELIABILITY
FLIR's award winning thermal technology is backed by the industry's most extensive warranty.

OVERVIEW
Array Format (NTSC)320 x 240
Detector TypeLong-Life, Uncooled VOx Microbolometer
Dimensions (L x W x H)285 x 96 x 94 mm/11.1" x 3.8" x 3.7" With sunshield and fully extended mounting arm
Effective Resolution76,800 pixels
Focal Length24mm
Focus RangeAthermalized, focus-free
Pixel Pitch12u
Sensitivity<50mK @ 25c F# 1.0
Spectral Range8 µm to 14 µm
