A light structure
Assembled structure: extruded anodized aluminum posts with multilayer side and back panels.
The unique transportable FH-drawer
The front of the trolley holds the drawers: there is room for 9 modules. This means any combination of our 1, 2 and 3 module drawers.
Drawers of 417×610 mm in injection moulded ABS plastic, lightweight yet very sturdy; full-width handle complete with wide label holder and coloured ID tag (available in 9 colours: red, green, yellow, blue, violet, grey, orange, pink and white).
Drawers on mauve plastic frame sliding on ball-bearing rails, fully extendable with self-closing and dampening system; load capacity of 45 kg for each drawer.
Centralized key-lock system for all drawers (as an alternative >>> electronic lock-system).
Worktop, panels and base
Worktop in moulded ABS plastic, with a 48 mm high rim on three sides and smaller frontal anti-drip edging.
Ergonomic push-handle on three sides with rounded corners and edges.
Overbridge available as accessory.
Base in moulded ABS plastic reinforced with a galvanised steel frame, with perimeter bumpers.
CONFIGURATION Space for 9 modules
This config: 5 FH drawers
2x 1 module
2x 2 modules
1x 3 modules
LEFT PANEL 3 tilt out bins
extendable work surface
RIGHT PANEL MAXIWALLY dustbin on SABU bar
OVERBRIDGE 3 universal accessory bars
1 row with 5 small bins
1 row with 4 large bins
WHEELS Ø 125 mm wheels with double ball bearing, swivelling, non marking and anti thread, 2 with brakes
DIMENSIONS (MM) 855 x 594 x 1015 H
LOAD CAPACITY 300 kg
