Additional information
Consider screed height of the base unit with tile sizes < 5 cm. Have product material and thickness of the screed defined by tiler
Natural stone tiles in the shower area may discolour
Technical data
Discharge rate 0.8 l/s
Depth of water seal 50 mm
Application purposes
For installation inside buildings
For drainage of floor-even showers
Suitable for less-abled installation
For composite seals
For screed height ≥ 90 mm at inlet
Characteristics
Quality-monitored in accordance with EN 1253-3
Suitable for tile structures on floor 2–40 mm
Premounted sealing fleece
Sealing fleece, 10 cm circumferential, for connecting sealing systems
Grating made of stainless steel
Grating can be aligned in height, inclination and offset
Base unit made of EPS, for sound decoupling and receiving the trap
Load-bearing capacity, class K 3 (3 kN)
Water drainage above the composite seal
Scope of delivery
Protection box cover with reference line
Thin bed bonding flange
Comb insert
Grating frame with compensation ring
Grating
Trap made of PE-HD
Adaptor ø 50 mm to G 2" (ø 55 mm)
Fastening material
Distance plate, thickness 2 cm
