CrossPointer5 SP is a Selection PRO product with special features.
Outstanding visibility of the laser lines
Combination of a 5 point and cross line laser
6 reference points at 90° to each other
Horizontal and vertical lines at 90° to each other
TECHNICAL DATA
Self-levelling range : ± 4°
Accuracy : ± 3 mm / 10 m
Line laser function 1 laser cross : front
Working range w/o receiver : 30 m*
Working range with receiver : 80 m (opional)
Sector angle Hz-line : 155°
Sector angle V-line : 160°
Point laser function : 5 laser dots : back, left, right, up, down
Working range w/o receiver : 30
Power supply / Operating time : Alkaline / 7 h
Dust / water protection : IP 54
Laser diode / Laser class : 635 nm / 2
Temperature range : -10°C - +45°C
Size : 115 x 70 x 115 mm
* depending on room illumination
FEATURES
2 laser lines form a laser cross
5 laser points: back, left, right, ceiling, floor
Plumbing function
Multi-functional mount
Strong magnets on the base
Strap attachment, rotatable
Use with receiver (optional)
Self-levelling function can be locked for manual use
SUPPLIED WITH
Multi-functional mount
Laser glasses
Magnetic target
Set of batteries
Container
