Door home automation system PRO

for distributed videofor home cinemasfor multimedia equipment

Overview
Wired automation system based on the KNX international standard, designed for advanced automation in residential buildings and small-to-medium offices. The solution is modular and highly configurable, supports integration with third-party devices and systems (video intercoms, smart locks, entertainment) and can be controlled via mobile APP, voice assistants or touch panels. Home & Building PRO also manages ZigBee devices and interfaces with Google Home, Amazon Alexa and IFTTT.

Benefits

• KNX international standard: Ensures interoperability between devices from different manufacturers and long-term compatibility for building automation projects.
• Advanced automation: Suitable for complex residential and small-to-medium office installations with extensive device counts and customized logic.
• Third-party integration: Enables integration of video intercoms (2N), smart locks (ISEO Argo) and entertainment/audio systems (SONOS) to centralize control of safety, comfort and energy functions.

Representative products / selected items (examples from the series)
Cod Gewiss | Description | Key data
GW90709 | SELF-PROTECTED ELECTRONIC POWER SUPPLY 220-240V - 50/60Hz - 320mA - IP20 - 4 MODULES - DIN RAIL MOUNTING | Output: 30V dc +/- 2V (SELV) - Current: 320 mA - 4 DIN modules
GW90710 | SELF-PROTECTED ELECTRONIC POWER SUPPLY 220-240V - 50/60Hz - 640mA - IP20 - 4 MODULES - DIN RAIL MOUNTING | Output: 30V dc +/- 2V (SELV) - Current: 640 mA - 4 DIN modules
GW90708A | LINE/FIELD COUPLING KNX - IP20 - 4 MODULES - DIN RAIL MOUNTING | Coupler - Repeater - 2 DIN modules
GW90706B | KNX/USB INTERFACE - IP20 - 1 MODULE - DIN RAIL MOUNTING | Max USB cable length: 5 m - 1 DIN module
GW90706U | KNX/USB STICK INTERFACE - IP20 | USB key - Dimensions: 60x19x13 mm
GW90802A | POWER SUPPLY 24VDC – 2.5A - 3 MODULES – DIN RAIL MOUNTING | Input: 100 ÷ 240 V ac - 50/60 Hz - Output: 24V dc - 2.5 A - 3 DIN modules

Additional information

• Control options: Mobile APP, voice assistants, touch panels.
• Protocols and interoperability: KNX standard, ZigBee management, compatibility with Google Home, Amazon Alexa and IFTTT.
• Target applications: Residential automation and small-to-medium office buildings; scalable to installations with many devices.
• Integration examples: Video intercom (2N), smart locks (ISEO Argo), audio/entertainment systems (SONOS).

Technical specifications

• Protocol: KNX (international standard)
• Wireless support: ZigBee device management via the platform
• Third-party platform integration: Google Home, Amazon Alexa, IFTTT
• Control interfaces: Mobile APP, voice assistants, touch panels
• Application scope: Residential buildings and small-to-medium offices
• System components: Power supplies, line/field couplers, KNX/USB interfaces, KNX/IP routers, actuators and sensors
• Power supply examples: 30V dc (SELV) variants (320 mA / 640 mA) and 24V dc 2.5A variants
• Mounting: Many components available for DIN-rail mounting
