Drainage channel with grating FASERFIX BIG BL

concretefiber-reinforced concreteiron

Drainage channels with precast reinforced concrete channel body. Our solutions – your benefits with FASERFIX BIG BL FASERFIX BIG BL linear channels integrated with a high stability reinforced concrete channel body are available in 4 metres and 1 metre lengths. FASERFIX BIG BL channels allow installation without the use of poured concrete and, once installed, are ready for immediate use without having to wait for the concrete surrounding to cure. Channel body made of concrete class C50/60 (exposure class XF4, XA3) with added basalt aggregate, reinforced with steel Available in four nominal widths: NW 100, 150, 200, 300 High hydraulic capacity: 220 I per 4-metre element with a cross-sectional area of 552 cm2 The 4 metre sections facilitate the rapid installation of even very long linear drainage lines, and the 1 metre sections are a convenient supplement to the lines Load class up to F 900 Possibility to choose colour and texture of surface according to project requirements FASERFIX BIG BL drainage channels have passed tests performed by the Air Force Institute of Technology in Warsaw. The Air Force Institute of Technology (ITWL) is a leading research centre for the support of military aviation technology supervised by the Minister of National Defence. The research carried out showed.
