Fluid dynamics calculation software WINPLATT

for steel structures

The WinPlatt program evaluates the plate load test acc. to DIN 18134. Also available : ÖNorm B 4417 (Austrian Norm) SN 670 317a (Swiss Norm) The data are entered into the form and can be calculated at the push of a button. Input: General data concerning the project description (such as building project, sampling point, date etc.), which can also be copied from other projects. Pressure gauge readings: Freely definable load level series or optional input. Settlements: Two input modes: One clock measure method with automatic inclusion of the index arm relationship. 3 clock measure method. Weathering data. Plate diameter, plunger diameter. Water content below plate, plate substratum. Specification of nominal values (the user can compile pre-set values in a file). Possibility of automatic data transfer of the measured values from a data acquisition device, with installed suitable IDAT program. Data transfer from ASCII files on demand. Analysis: The evaluation takes place acc. to DIN 18134 2001-9 (polynomial 2nd order). Calculation of the deformation modules Ev1, Ev2 and if necessary Ev3, as well as the relationship Ev2/Ev1. Evaluation acc. to Austrian-Standard (B4417) and Swiss Standard (SN 670 317a). Output: Output of all project tests in a printer list. Complete output on the printer inclusive diagrammatic representation. BMP-Export. DXF-Export. EMF-Export. Layout preview. The grid scale can be taken over by the program or be individually defined.
