Hanging lighting profile PIKO-O

LEDcommercial

PIKO-O Extrusion Ref: C1167 Miniature external dimensions (outer diameter 0.41'') Smooth exterior walls for a modern look Easy bending of the extrusion Narrow, subtle line of light Technical specification Application General purpose profile. Assembly With conductive end caps. Additional information - the lighting fixture is 360 degrees rotatable when coupled with PIKO-O conductive end caps, - PIKO-O is compatible with 0.20"/ 5 mm wide LED strips, - the PIKO-O extrusion is available as silver anode and black anode, - maximum deflection of the PIKO-O extrusion at a length of: - 118" / 3 m is 1.78" / 45 mm, - 78.7" / 2 m is 0.98" / 25 mm, - 68.9" / 1.75 m is 0.59" / 15 mm, - 59" / 1.50 m is 0.39" / 10 mm, - 47.2" / 1.20 m is 0.19" / 5 mm, - 39.4" / 1 m is 0.08" / 2 mm, - space for LED strip: 0.25" / 6.2 mm. The PIKO-O conductive end cap is designed for single-pole conductivity. The maximum forward current for the PIKO-O conductive end cap is 2 A.
