• 1,5 mm thickness work top is made of AISI 304 stainless steel
• High performance stainless steel burner
• The plate is made of 15 mm thick tempered ST52 steel
• Removable oil collector can be easily emptied
• Appliance could be used with natural gas or LPG. Gas nozzles also put in appliance package for conversion.
• Thanks to oil channel and large drain hole, make cleaning easy
• High flame burner provides uniform heat distribution on plate surface.
• Piezoelectric ignition system
• It can be use on the bench , can be mounted on base cupboard or cantilever systems
• Magnet safety gas valve with pilot flame is used.
• Compliance with CE standards and directives.
• Flame failure device (thermocupl), cuts the gas when accidentaly flame goes out; prevents gas leakage
UMPI04G01
DIMENSION (MM)
400x700x250
PACKING DIM. (MM)
450x800x470
CONSUMPTION NG-(M³/ H) -LPG-(KG/H)
0,63 – 0,47
POWER (KW)
6
UMPI04G01-1/1
DIMENSION (MM)
400x700x250
PACKING DIM. (MM)
450x800x470
CONSUMPTION NG-(M³/ H) -LPG-(KG/H)
0,63 – 0,47
POWER (KW)
6
UMPI04G03-1/0
DIMENSION (MM)
800x700x250
PACKING DIM. (MM)
850x800x470
CONSUMPTION NG-(M³/ H) -LPG-(KG/H)
1,27-0,94
POWER (KW)
12
UMPI04G03-1/2
DIMENSION (MM)
800x700x250
PACKING DIM. (MM)
850x800x470
CONSUMPTION NG-(M³/ H) -LPG-(KG/H)
1,27-0,94
POWER (KW)
12
UMPI04G03-1/1
DIMENSION (MM)
800x700x250
PACKING DIM. (MM)
850x800x470
CONSUMPTION NG-(M³/ H) -LPG-(KG/H)
1,27-0,94
POWER (KW)
12
