Flexible LED light strip A4902-600-5662

Led bar is built with Honglitronic chip, version HL-A-5730D49W-S1-HR3. A very narrow range of colour temperature between 6000-6500K ensures colour stability for different lots. You can find the Led datasheet. This led bar has no resistors for a constant current drive. It is made of 8 parallel branches with a series of 7 leds for a total of 56 leds. Power applied to the bar can vary depending on the heat sink used and its uses. Recommended current range for a single led is between 50mA and 120mA. A thermal adhesive is applied on the back side to allow a fast installation and the correct heat dissipation. Features: Led 5730 LED Bar colour temperature: 6000-6500K Led bar with 56 leds (8 parallel branches with a series of 7 leds). Power supplying: constant current, from 0.40A to 0.96A max, aprox. maximum power 21W ATTENTION: do not employ constant voltage power supplies. Sign '+24V' indicates positive pole only Length 490 mm, 12 mm, 3 mm Color PCB: White Power cables on one side of the bar Product code: A4902-600-5662 The bar has several applications, as: Llighting of wardrobes, cupboards, shop windows, tables, shelves, etc. Direct or indirect lighting of ceilings Backlighting TV's Genercic furniture lighting; Modding and tuning, especially for black background strips
