Roller blinds RECTA

for windowaluminiumlacquered aluminum

Product overview
Clean lines and precise angles define Recta: a made-to-measure roller shade by Maanta featuring a square geometric aluminium decorative plate that conceals the mechanism and provides a minimalist architectural aesthetic. Manufactured in Italy; typical production time indicated on site: approx. 12–15 working days.

Key features

• Optional USB-C rechargeable battery motor: no fixed wiring required.
• Tens-Flow system for constant fabric tension and smooth travel; prevents creases and sagging.
• Fabrics certified to EN 14501: 28 variants from sheer to full blackout with measured solar performance.
• Exclusive square aluminium decorative plate in six finishes; two front widths (Slim, Standard).

Fabric types (light control)
Selectable fabric categories in the configurator: Blackout, Filter (light-filtering) and Light (transparent). Collections include Blend Blackout, Canvas Blackout, Horizon, Fine Line, Earth, Satin, Brush and Diamond.

Plate and aesthetic options
The Recta plate is powder-coated aluminium available in six finishes. Slim front width ≈ 43–47 mm (depending on reference); Standard ≈ 76–79.5 mm (depending on reference). Both widths support wall or ceiling mounting.

Operation & motor

• Operation modes: manual chain control or motorised (12V tubular motor with integrated rechargeable battery, USB-C).
• Motor features: USB-C rechargeable Li‑ion battery, quiet operation (≤35 dB), three adjustable speeds, integrated 433.92 MHz receiver; optional Wi‑Fi Bridge for smart‑home integration.
• Functions: favourite position, soft stop, jog mode, overload protection; battery autonomy depends on use (page indicates up to one year under typical conditions).

Sizes, installation and measurement
Made-to-measure product. Configurable width range 60–280 cm and height range 30–300 cm. Final fabric width equals total width minus plate widths. Universal mounting kit included for wall or ceiling installation. Manual chain option may be restricted by installation height for child-safety; measurement guide available on site.

Technical specifications & contents

• Model: Recta
• Manufacturer: Maanta
• Structure: powder-coated aluminium
• Roller diameter: 40 mm
• Fabric collections: 8 collections, 28 variants (EN 14501)
• Plate widths: Slim ≈ 43 mm / Standard ≈ 76 mm
• Motor (optional): rechargeable via USB-C, 433.92 MHz receiver, ≤35 dB, three speeds
• Operating temperature motor: -10 °C to +60 °C
• Package: assembled shade, Recta plate, mounting kit; if motorised: motor + USB-C cable included
• Warranty: 2 years
