Gas convector H3 1 PANEL

2501 w...3000 wcontemporarymetal

FEATURES Balanced flue type.Exhaust gases cannot escape into the room. In case of exhaust draft failure,the gas is shut off to the burner by thermocouple ,turning the heater off. Flame Failure Safety Device turns off the gas in case of flame failure. High heating efficiency and fuel savings. SUPREME DETAILS Pilot light safety and battery ignition system. Special flue terminal provides efficient combustion in windy conditions. Gas pressure is set. Pressure increase in the gas line does not affect fire. Pressure regulator ensures the same gas flow and efficient operation. Perfect gas combustion is ensured due to the combustion chamber design. Adjustable thermostat reduces fuel consumption and keeps the room temperature. Thermal efficiency is increased by the number of air shutters. Inner ceramic glass is resistant to thermal shock. Wall mounted provides space. Guaranteed for 2 years. Technical Type of Fuel Natural Gas – LPG Gas Inlet Pressure 20 – 30 mbar Burner Inlet Pressure 12 – 26 mbar Nominal Power kwh : 3 kcal/h : 2470 Thermal Efficiency 84% Gas Consumption 0,30m3/h – 0,23kg/h Exhaust Pipe Diameter ø 80 mm Air Inlet Pipe Diameter ø 150 mm Gas Connection ø 1/2″ R Depth 160 mm Weight 14 kg Width 500 mm Height 600 mm
