Folding partition NW 545

sliding and stackingwoodenglass

Interior Wood Framed Folding Glass Wall for Superior Acoustical Control • Quadruple laminated, cross-grained wood frame delivers exceptional acoustical performance up to unit STC 41 • Intersection of two folding panels is 5 11/16" (144 mm) • Floor supported panels capable of heights up to 9' 10" (3000 mm) NW Acoustical 545—Up to Unit STC 41 Possible NW Acoustical 545 is the first floor supported, wood framed folding glass wall able to achieve sound control up to an impressive unit STC 41. This system combines solid, single species wood framing and specialized gasketing with sound-enhanced glass to achieve optimal performance with the range of unit STC from STC 31 up to STC 41—all while allowing maximal transparency and natural daylight to flood interior spaces. Minimal Sightline Equals Increased Transparency With an extremely thin wood frame profile, NW Acoustical 545 is specifically engineered for workplace applications and for interior spaces where acoustical privacy and ease of use are of utmost concern. ADA Compliant Flush Sill for Workplace Design The Flush sill option is ADA compliant with an aluminum floor track insert that provides high heel protection. This sill can be installed directly over finished flooring to create clean transitions between interior spaces. Left/Right FourFold and SixFold Panel Sets for Larger Openings and Flexible Stacking This Generation 4 wood framed interior folding system allows for larger opening sizes and flexible space management with the integration of FourFold or SixFold panel sets.
