Wall-mounted shower head ROUND

ceiling-mountedroundrain

Description
ROUND is a 20 cm rain shower head with a ball joint for orientation. Made in AISI 304 stainless steel with a safety/overpressure valve included. Standard flow rate is 9 L/min at 3 bar.

Finishes

• Polished stainless steel
• Matt black

Features

• Rain spray pattern
• Anti-limescale system
• Safety/overpressure valve included
• AISI 304 stainless steel construction
• Noken Eco-Flow
• Waterforest
• Certifications: DVGW, WRAS

Compatible aerators / Flow options (flow rate at 3 bar)

• 12 L/min — compatible with 100072956
• 9 L/min — compatible with 100072961
• 8 L/min — compatible with 100116247
• 7 L/min — compatible with 100165560
• 6 L/min — compatible with 100072959
• 5 L/min — compatible with 100301687

Spare parts — Version A00 (table)
Pos. | SAP | Art. | RRP (excl. VAT)
0010 | 100268622 | 1/2" GASKET WITH MESH FILTER | 4,00 EUR
0020 | 100268606 | FLOW LIMITER 9 L/MIN FOR RAIN SHOWER WITH VALVE | 5,00 EUR
0030 | 100268616 | BALL JOINT FOR SHOWER HEAD WITH VALVE CHROME | 18,00 EUR
0040 | 100268618 | SAFETY VALVE FOR SHOWER HEAD | 7,00 EUR
0050 | 100268617 | UNION GASKET FOR BALL JOINT WITH VALVE | 4,00 EUR
0060 | 100253676 | BAG OF 25 SPARE NOZZLES FOR HOTEL SHOWER HEADS | 13,00 EUR

Technical characteristics / specifications

• Model name: ROUND
• Reference / item code: 100266462
• Diameter: 20 cm
• Type: rain shower head (wall-mounted / overhead)
• Joint: ball joint for orientation
• Security: safety/overpressure valve included
• Material: AISI 304 stainless steel (polished finish option)
• Flow rate (standard): 9 L/min at 3 bar
• Available finishes: Polished stainless steel, Matt black
• Anti-limescale system included
• Eco features: Noken Eco-Flow, Waterforest initiatives
• Certifications: DVGW, WRAS
