Polycarbonate canopy cycle shelter Abri-velos 21SF

modulardesigninclined

Description
The 2-SAIL-26 bicycle shelter features a contemporary design with a rounded roof sloping rearwards that forms an integrated back panel. Side panels are available as an option. The unit is modular in length (example module: LN 4 m).

Frame
Structural frame in hot-dip galvanized steel providing anti-corrosion protection.

Finish
Finish options: GALVA or GALVA + thermo-lacquering (RAL colour selectable by the client).

Roof
Quarter-circle roof in 4 mm clear translucent polycarbonate (PCC) glazing, inserted into profiles with neoprene sealing joints.

Safety and compliance
Structure engineered to comply with or exceed DTU requirements and the Snow and Wind standard NV 65. Standardised components ensure professional performance regarding thermal expansion, water drainage and fixings.

Dimensions
Maximum height: 2.05 - 2.15 m. Roof depth: 2.30 m.

Options and anchoring
Optional lateral panels in HPL (Formica/Trespa type), highly durable and coloured through the mass. Anchoring: feet fixed via baseplates to massifs or reinforced concrete slab (min. thickness 15 cm). Suggested 4 footings (min. depth 500 mm, width 250 mm). Civil works to be organised by the client.

Technical specifications

• Model: 2-SAIL-26
• Theme: Bicycles and 2-wheel vehicles
• Category: Open bicycle shelters / motorcycle shelters
• Ref: ABR2SAIL26
• Frame: hot-dip galvanized steel
• Finish: GALVA or GALVA + thermo-lacquering (RAL colour selectable)
• Roof: 4 mm translucent clear polycarbonate (PCC), quarter-circle profile
• Sealing: neoprene joints
• Compliance: compliant with or superior to DTU and Snow & Wind standard NV 65
• Main dimensions: max height 2.05–2.15 m; roof depth 2.30 m
• Anchoring: baseplates on massifs or reinforced concrete slab (min. thickness 15 cm)
• Optional side panels: HPL (Formica/Trespa type)
