Metal roofing panel PAC T-250

standing seam

Standard is smooth panel Maximum factory-produced panel length is 54 ft. (check w/factory for longer lengths) Architectural/structural panel Factory-applied sealant in seam cover Continuous interlock 30-year non-prorated finish warranty Weathertightness warranty available PAC T-250 panels are factory-formed or field-formed to length and field-seamed. The panels have been designed for application over a wide variety of substrates on roof slopes as low as 1/2 : 12. PAC T-250 panels can be produced in 22 and 24 gauge steel or .032 and .040 aluminum. The PAC T-250 panel combines structural performance with architectural aesthetics. PAC T-250 panels feature a 2.625” nominal finished panel height from the deck that requires mechanical field seaming after installation. The panels have a continuous and/or intermittent concealed-fastener clip system designed to allow for thermal expansion/contraction. Sealant beads are factory-applied to the seam cover. Trim All flashing and trim shall be fabricated by Petersen or a qualified fabricator. Flashing shall be PAC-CLAD aluminum or steel. A 30-year non-prorated finish warranty can be supplied covering finish performance. Vinyl film is recommended on all fabrication applications where extra handling is expected. NOTE: The strippable film must be removed immediately after installation.
