Pair of handles in AISI 316L stainless steel on solid rectangular plate. Plate Width 130 mm, height 145 mm, thickness 4 mm, overhang 48 mm. Rectangular lever handle 30 mm x 130 mm, thickness 4 mm. With return spring. Spindle in steel with corrosion resistant treatment 8x8mm. Without hole for cylinder. Throughout fixing kit included with stainless steel screws. Standard satin finish (bright finish and other finishes on request).
Stainless Steel AISI 316L
.44 - SATIN
.43 - BRIGHT
.83 - PVD Black Satin
.40 - POWDER COATED Black
.31 - POWDER COATED White 9010
.32 - POWDER COATED Grey
.38 - POWDER COATED Champagne
.39 - POWDER COATED Bronze
.41 - POWDER COATED Silver
.99 - POWDER COATED
