Anti-radiation door

interiorsolid woodlaminate

The doors for hospitals hâve a 46 mm finishing thickness. Finishing is made up of seven layers: - - central layer in lead foil from 1 to 3 mm; - - 2 panels of extra-hard high density minerai fiber of mm.4; - - honeycomb panel surrounded by double perimeter frame, honeycomb in phenolic resin-coated cardboard; - - 2 plastic laminates 9/10 thickness; by default the color is white or sand - - X-ray lead with first melting lead sheet mm. 2 calibrated and brushed. - any lead thickness on request. the FRAME of the doors for healthcare facilities: It is made of solid wood with lead foil. Interlocking architraves with interposed lead foil. A) Profile for panel stop and seat for inserting the profile B) Trims / External exhibition with interposed lead foil with counter frame cover function (variable for walls from 10 cm up to 13 cm) the HINGES of the anti-x doors: 5 hinges according to the thickness of the lead used and according to the door size: The hinges are of the bearing type and adjustable for easy adjustment. The capacity of each hinge is Kg. 125. The x-ray door handles are made of thick aluminum and of the accident prévention type. The lock for leaded doors is of the patent type with a CE marked key complying with the EN 12209 standard. Or provision for yale cylinder. Choice of standard color finishes; non-standard available as extras. Lead in accordance with UNI 6450-69 standards, quality 99.9% min. Lead with radiometric value in the standard according to Legislative Decree No. 230 of 17/03/1995. Followed by certificate of conformity.
