Preamplifier PHONO BOX E

Entry-level audiophile MM phono stage Today, many amplifiers do not have a specific phono cartridge input. Phono Box E is an ideal phono preamplifier for these hifi systems. Phono Box E accepts MM cartridges and offers an audiophile music experience at an entry-level price. Advanced circuitry and SMD construction keep noise and distortion at a surprisingly low level. A built-in internal shielding and an outboard DC power supply leave no risk for external interference. Because of its small casing, Phono Box E can be placed near the turntable. Input and output sockets are gold-plated for preservation of quality. Phono Box E can be connected easily to a line-input (AUX etc) of your amplifier. • Amplification and RIAA equalisation for MM cartridges • Design principle inspired by Dr. Sykora • SMD circuitry • Special low noise components • Internal metal shielding • Small size allows installation close to record player • Gold plated RCA connection sockets • Outboard power supply included • Black or White casing TECHNICAL SPECIFICATIONS Input impedance47kohms Input capacitance120pF Gain40dB Output voltage(typically)500mV @ 1KhZ with 5mV inpu tNoise floor88dB (A weighted) THD<0,04% RIAA equalisation accuracy20Hz –20kHz (+0,5/ -,02dB) Input1 pair RCA socketOutput1 pair RCA socket Outboard power supply18V/500mA DC; 220 - 240V, 50Hz Standby power consumption< 1 watt Power consumption 20mA DC Dimension W x H x D (D with sockets) 4.72 x 1.26 x 3.94 (3.53) in Weight .55lb without power supply
