Logistic Data
Article No.
43519192
Code
RL-PAR16 35 DIM 927/WFL
Product EAN
4008597191923
Box quantitiy (pcs.)
10
EAN Box
4008597491924
Gross weight of box in kg
0.603
Length of box in m
0.26
Width of box in m
0.11
Height of box in m
0.07
ETIM class
EC001959
ETIM class name
LED-lamp/Multi-LED
Product status
Active
Electric Parameters
Nominal power
3,7 W
Rated wattage
4.5 W
Weighted energy consumption in 1,000 hours
3,7 kWh
Power factor
> 0,8
Nominal voltage
220-240 V
Voltage type
AC
Nominal current (mA)
26 mA
max. no. of Lps with 16A (B) circuit breaker with ballast (ECG, CCG no capacitor) / at mains
379
max. no. of Lps with 10A (B) circuit breaker with ballast (ECG, CCG no capacitor) / at mains
237
Light Application Parameters
Rated lamp luminous flux
230 lm
Luminous flux in 90°-sector
230 lm
Luminous intensity
630 cd
Beam angle
36 °
Luminous efficiency
62,16 lm/W
Colour temperature
2700 K
Colour rendering index Ra
≥ 90
Coloure rendering index Ra nominal
90
Colour Stability
≤ 5 sdcm
Service Life
Mean service life
25000 h
Average nominal lifespan
25000 h
No. switching cycles
100000
Lamp survival factor at 6000h
≥ 0.90
Early failure rate at 1000h
≤ 5.0 %
Specification
Diameter max.
51 mm
Diameter
51 mm
Length max.
55 mm
Length
55 mm
Mercury content
0.0 mg
dimmable
ja
Lamp shape
Reflector
Finish
glass
Degree of protection (IP)
IP20
Colour
White
Notes on Operation
Ambient temperatures
-20…+40 °C
Ambient temperature range operation
-20…+40 °C
