Entry door ICAT®anodized aluminumplasticpolyamide
Add to favorites
Compare this product
Characteristics
- Type
- entry
- Material
- glass, anodized aluminum, plastic, polyamide
- Opening system
- telescopic
- Style
- contemporary
- Glazing
- glazed, double-glazed
- Glass finishes
- clear glass
- Configuration
- double leaf
- Security level
- automatic closing
- Technical characteristics
- security, electric, thermally-insulated, waterproof, high-resistance, wind-proof, emergency exit
- Color
- customizable color
- Applications
- for high-traffic areas
- Other characteristics
- custom, with fixed leaf, double-leaf
- Ecological characteristics
- sustainable, made from recyclable materials, energy-saving
- Resistance class EN 1627
- resistance class RC2, resistance class RC6
Description
Thanks to its compact dimensions, the iCat® A110 fits perfectly into any architectural environment, even in confined spaces.
FRONT COVER
Available in natural or anodized aluminum.
Plastic safety "parachute" that can be easily installed together with the fuselage.
Narrow and wide series wings.
Designed for locking in open position for easy installation.
DRIVE GROUP
24 Vdc gear motor with optical reader.
Control unit.
Complete with 2 wheels or 4 wheels (for the iCat A110 2-wing version)...
WHEELS
Aluminum
2 polyamide support wheels.
Wheel height adjustment (+-) 7,5 mm
iCat A110 CONTROL UNIT
iCat control unit microprocessor with locking batteries and electromechanical locking system.
220 Vac circuit on/off power unit.
Removable terminal panel.
Automatic adjustments
Open and closed position definition.
Speed selection, optimal acceleration or deceleration.
Photocell test.
150 N force impact protection device during operation.
Speed adjustment and KUR application option possible directly on the card (no external program required)
RESET (restart) function.
4 adjustable output points.
2 emergency entry points.
Locking function.
Alarm function.
LCD display to detect status and damage.
Opening and closing speed adjustment.
Pause timing.
Night pause.
Motor lock.
