Recessed fan coil MAESTRO

duct

The MAESTRO fan coil units are for concealed installation and connection to a duct system. They supply a consistent air flow with static pressure up to 150 Pa. The MAESTRO Fan Coil Units are manufactured in 5 sizes for hot water supply (11-42 kW) and chilled water supply (4-16 kW). The Maestro high pressure fan coils are produced in 5 sizes. Designed and built for concealed installations, they have small dimensions, are very silent and have a particularly interesting price in relation to their performance (all sizes, even at the lowest speed, have a residual pressure head of at least 160 Pa). They are suitable for climate control for small and medium commercial and sports environments or for large civil environments and integrate perfectly in regular false ceilings. Each size is equipped with 4 speed fans, 3 of which are connected to the terminal board. The base models call for a 4 row coil but upon request, units with 3 row coils or additional coils (for 4 pipe systems) with one or two rows can be provided. A complete set of accessories solves any type of system problem. Casing: made with galvanized steel insulated with polyolefin (PO) foam (class M1). Fan assembly: consists of quiet centrifugal fans in galvanized steel with two impellers and a directly driven single phase, four speed motor, 230V 50Hz, with capacitor, insulation class B. Coil: it is manufactured from drawn copper tube and the aluminium fins are mechanically bonded onto the tube by an expansion process.
