Access lifting platform ZENITH MC/PC

for construction sitefor industrial useoutdoor

The MC/PC abbreviation stand for transport climbing platform, the certified access platforms manufactured by SAFI in Italy can be used for lifting material & personnel by a ground or on board command. The Zenith MC/PC has different loads capacity which start from 1500/2000/2500/3000 kg, Safi’s transport platform has a standard dimension of 3.00 x 1.50 meter with an open top cage, The strong dimension of the material hoist Zenith MC/PC makes it a perfect solution to load huge quantities of equipments, material & personnel this is to accelerate construction process , the access platform can be installed in industrial & construction sectors, rack and pinion transport platform can be also manufactured according to client needs & specifications or the site needs. The material & personnel lifting hoist has an innovative design which meets all CE safety requirements for working in safety. The rack and pinion system in such machines gives the possibility to reach the maximum height of 250 meters. The industrial lifting platform has different shapes of mast sections ( Triangular, Square 750 x 750 & Flat ) controlled by a specific number of electric gear motors made in Germany with a standard speed of 12/24 meter per minutes. The platform can be operated in different climate ( from – 40 till +55 ) The Colour , Speed, dimensions & entrance & exit doors can be customised as per client needs & requests. Maximum height (m) - 200 Type of Vertical element - Square section mast Height of vertical element - 1482 Weight of vertical element (daN) - 102,0 Max. height without anchorage points (m) - 9,0 Max. distance between anchorage points (m) - 9,0 Total maximum capacity (daN) - 2000
