Safety glass panel INSIO®

low-einsulatingacoustic

Overview
INSIO® is a next-generation vacuum glazing solution designed to provide high thermal and acoustic insulation. Its core consists of a thin vacuum gap of less than 0.3 mm between two glass panes, significantly reducing heat and sound transmission compared with conventional double or triple glazing. Using tempered safety glass allows fewer internal support pillars, enabling a slimmer glazing profile and very low Ug values, in some cases lower than leading triple glazing. Combined with a low-emissivity coating, INSIO® delivers premium energy performance while maintaining an elegant appearance, suitable for sustainable buildings, renovations and architectural projects.

CLIMAPLUS® INSIO®
CLIMAPLUS® INSIO® pairs the insulating properties of INSIO® (transparent insulation) with the practicality of a standard insulating glass unit. By integrating INSIO® into a conventional insulating glazing using a standard spacer and an outer lite, CLIMAPLUS® INSIO® achieves a standard unit thickness that simplifies installation in existing window systems. The outer lite can be selected from the Saint-Gobain Glass range to meet thermal, acoustic, solar control or aesthetic requirements. CLIMAPLUS® INSIO® is CE marked in accordance with EN 1279:2018.

Applications

• Replacement of existing glazing while retaining the existing window frame (renovation, restoration, listed buildings).
• Full window replacements for retrofit or new build, configured as CLIMAPLUS® INSIO® to behave like conventional insulating glass.

Benefits

• Thermal insulation: superior to the best triple glazing; Ug between 0.5 and 0.3 W/m²K depending on INSIO® version and outer lite chosen for CLIMAPLUS® INSIO®.
• Thin profile: considerably thinner and lighter than traditional triple glazing; standard INSIO® thickness: 10 mm (8 mm and 12 mm options available on request).
• Durability: INSIO® is covered by a 20-year warranty under defined conditions; inorganic sealing of the vacuum glazing provides extended service life.
• INSIO® and CLIMAPLUS® INSIO® carry CE marking.
• Ease of integration: INSIO® can be integrated into a CLIMAPLUS® insulating unit to improve thermal and acoustic performance; compatible with common window frames.
• Acoustic performance: better than standard double or triple glazing; certified acoustic measurement for INSIO® 10 mm: Rw = 35(-2,-2) dB.
• Energy efficiency: reduces heating and cooling demand, contributing to lower energy bills and building sustainability.

Performance — INSIO® (measured)
INSIO® is composed of two tempered glass panes with a low-emissivity coating.
INSIO® 10-C1 — Faces: 2; Total thickness: 10 mm; Ug: 0.5 W/m²K; Visible transmittance (TL): 77%; Solar factor (g): 63%; External reflection (RLe): 15%; Internal reflection (RLi): 14%; Rw: 35(-2,-2) dB.
INSIO® 10-C2 — Faces: 2; Total thickness: 10 mm; Ug: 0.3 W/m²K; TL: 69%; g: 39%; RLe: 14%; RLi: 14%; Rw: 35(-2,-2) dB.
INSIO® 10-C3 — Faces: 2; Total thickness: 10 mm; Ug: 0.3 W/m²K; TL: 63%; g: 30%; RLe: 13%; RLi: 13%; Rw: 35(-2,-2) dB.
Sources of measurements: ISO 19916-1, EN 410 and laboratory evaluations according to ISO 10140-2:2021 and ISO 717-1:2020 (sample 908 mm x 2127 mm).

Performance — CLIMAPLUS® INSIO® (calculated configurations)
Insulating double glazing with INSIO® 10-C1 used as inner lite (configuration: outer lite/10-14 Ar/INSIO® 10-C1; outer lite = selected counter-glass).
CLIMAPLUS® INSIO® - 4 mm Clear outer lite — Total thickness: 28 mm; Ug: 0.5 W/m²K; TL: 71%; g: 62%; RLe: 20%; RLi: 20%.
CLIMAPLUS® INSIO® - STADIP® PROTECT 44.2 outer lite — Total thickness: 28 mm; Ug: 0.5 W/m²K; TL: 70%; g: 56%; RLe: 19%; RLi: 20%.
CLIMAPLUS® INSIO® - 4 mm ECLAZ® LUMI outer lite — Total thickness: 28 mm; Ug: 0.4 W/m²K; TL: 71%; g: 57%; RLe: 16%; RLi: 17%.
CLIMAPLUS® INSIO® - 4 mm ECLAZ® ZEN outer lite — Total thickness: 28 mm; Ug: 0.4 W/m²K; TL: 68%; g: 46%; RLe: 20%; RLi: 20%.
CLIMAPLUS® INSIO® - 4 mm ECLAZ® SUN outer lite — Total thickness: 28 mm; Ug: 0.4 W/m²K; TL: 62%; g: 34%; RLe: 18%; RLi: 20%.
CLIMAPLUS® INSIO® performance data: calculated according to ISO 19916-1 and EN 410.

Technical specifications

• Composition: two tempered glass panes + low-emissivity coating + vacuum gap (<0.3 mm).
• INSIO® thicknesses: standard 10 mm; other options: 8 mm and 12 mm (on request).
• Typical Ug: between 0.5 and 0.3 W/m²K depending on version and configuration (INSIO® and CLIMAPLUS® INSIO®).
• Certified acoustic performance for INSIO® 10 mm: Rw = 35(-2,-2) dB.
• Available dimensions: max 1524 mm x 2438 mm; min 305 mm x 457 mm.
• Lead time: indicative 4 to 10 weeks (varies with specification).
• Warranty: INSIO® covered 20 years under INSIO® general conditions; inorganic sealing ensures extended durability.
• Marking: CLIMAPLUS® INSIO® is CE marked (EN 1279:2018).
• Integration: can be used as an insert within a CLIMAPLUS® insulating unit to fit standard frames or to replace glazing in existing frames.
