Full-extension - Pin-fix version - 6528
Full-extension runner system fixed to the drawer by locating pin - -
- INTEGRATED PUSH SYSTEM
- INTEGRATED SMOVE SYSTEM
- RUNNER - LENGTH FROM 300 TO 500 MM
- DRAWER FIXING SCREWS
- PIN-FIX CLIP PREMOUNTED ON THE RUNNER
- FULL-EXTENSION -
Two technologies in just one runner
The Unica full extension concealed runner combines Smove decelerated closing action with both traditional opening and Push self-opening for handle-less furniture.
Equipped with the integrated Push system for handle-less furniture and with the integrated decelerating Smove system. The fully integrated operating system is completely mechanical and therefore does not require a power source.
Full-extension runner system fixed to the drawer by locating pin.
The Push self-opening system for handle-less drawers is fully integrated into the runner. A slight pressure on the drawer frontal is sufficient for the drawer to self-open.
The Smove decelerated closing action is also fully integrated into the runner.
Safety system that secures the drawer to the runner.
Drawer height adjustment +3 mm and depth adjustment ±2 mm.
The drawer is maintained parallel with the cabinet side during opening.
Drawer fixing without screws.
Finish: bright zinc-plated.
